• High quality polyester substrate
• Sealed enclosure, dust and colophony proof, protected against harmful influences
• Double wiper, dual support
• Excellent stability, multipurpose applications as variable film potentiometer
• Resistant against cleaning agents, ultrasonic cleaning possible
|
 |
Electrical Specifications
|
|
|
|
Taper:
|
Linear
|
Power Rating (TU = 40°C):
|
0,25W
|
Operating Voltage, Max.:
|
250V DC
|
Resistance Tolerance
|
£1MW:
|
±20%
|
>1MW:
|
±30%
|
Temperature Range:
|
-25...+70°C
|
|
Mechanical Specifications
|
|
|
|
Rotation
|
Mechanical:
|
265 ±5°
|
Electrical:
|
250 ±20°
|
Torque (3...5U/s):
|
0,5...2,5Ncm
|
Stop Torque:
|
10Ncm
|
|
|
|
|
Diameter:
|
15mm
|
Depth:
|
6mm
|
|
| Labelling |
Resistance and production date code.
|
|
|
