Fiber Optic Rec. Module -27dBm 6Mb/s

Name: Fiber Optic Rec. Module -27dBm 6Mb/s
SKU: 79684
Price: 475.00 DKK
Availability: OutOfStock

Varenummer: 79-684

Varekode: TORX176

0 stk. på lager

Vis lignende produkter i kategorien "Modtagere"

Technical Specifications

• Operating temperature range, min. -20...+70°C


Part Nr.	Data Rate	P_min	P_max	I_CC
	[Mb/s]	[dBm]	[dBm]	[mA]
TORX111	DC...6	-22	-4,5	20
TORX147PL	0,1...15	-24	-14,5	15
TORX173	DC...6	-27	-14,5	40
TORX176	DC...6	-27	-14,5	40
TORX193	DC...6	-27	-14,5	40
TORX194	DC...10	-29	-18	40
TORX196	DC...6	-31	-14	40
P_min = Min. Receivable Power, P_max = Max. Receivable Power, I_CC = Max. Supply Current

Manufacturer

Toshiba
http://www.semicon.toshiba.co.jp/eng
