Fiber Optic Transm. Module -21dbm 6Mb/s

Name: Fiber Optic Transm. Module -21dbm 6Mb/s
SKU: 79674
Price: 312.25 DKK
Availability: OutOfStock

Varenummer: 79-674

Varekode: TOTX176

0 stk. på lager

Vis lignende produkter i kategorien "Sendere"

Technical Specifications

• Operating temperature range, min. -20...+70°C


Part Nr.	Data Rate	P_f	WL	I_CC
	[Mb/s]	[dBm]	[nm]	[mA]
TOTX111A	DC...6	-12	670	40
TOTX141P	DC...15	-21	650	20
TOTX173A	DC...6	-21	650	20
TOTX176A	DC...6	-21	650	20
TOTX193	DC...6	-21	660	25
TOTX195A	DC...10	-11	670	40
TOTX196B	DC...6	-20	800	55
TOTX197A	DC...6	-15	650	30
P_f = Min. Fiber Output Power, WL = Peak Emisssion Wavelength, I_CC = Max. Supply Current

Manufacturer

Toshiba
http://www.semicon.toshiba.co.jp/eng

Inkl. moms

Kr. 312,25

79-674

/ TOTX176

0 stk. på lager

Technical Specifications

• Operating temperature range, min. -20...+70°C


Part Nr.	Data Rate	P_f	WL	I_CC
	[Mb/s]	[dBm]	[nm]	[mA]
TOTX111A	DC...6	-12	670	40
TOTX141P	DC...15	-21	650	20
TOTX173A	DC...6	-21	650	20
TOTX176A	DC...6	-21	650	20
TOTX193	DC...6	-21	660	25
TOTX195A	DC...10	-11	670	40
TOTX196B	DC...6	-20	800	55
TOTX197A	DC...6	-15	650	30
P_f = Min. Fiber Output Power, WL = Peak Emisssion Wavelength, I_CC = Max. Supply Current

Manufacturer

Toshiba
http://www.semicon.toshiba.co.jp/eng
