Thermal Fuses 98°C 15A
Varenummer:
151-638
Varekode: NTE8096
21 stk.
på lager
Specifikationer
| Temperatur | 98 °C |
|---|---|
| Strøm, max. | 15 A |
Gruppe: E1117
NEC Micro-Thermal Cut-off Fuses
Series: SF/E
Axial
Rated Current: 15A
| Features |
| • For installation on or in the heating device of electric household appliances, transformers and all types of devices • sealed against hazardous influences such as dust, oil, insulating varnish, cast resin and grease • TSF142E-1: with long pins (2x 35mm) |
 |
| Technical Specifications |
|
|||||||||||||
| Contact: | NC | Housing: | Metal | Rated Current: | 15A | Rated Voltage: | 250V AC | Temperature In Continuous Test 1): | Conforms To VDE 0821 | Operating Life: | Conforms To VDE 0821 | ||
| 1) The Rated Functioning Temperature |
|||||||||||||
|
|||||||||||||
| Part Nr. | TRated | TTrip Current | [°C] | [°C] | TSF073 | 73 | 70±2 | TSF077 | 77 | 76+0/-4 | TSF094 | 94 | 91+3/-1 | TSF099 | 99 | 96±2 | TSF113E | 113 | 109+3/-1 | TSF121 | 121 | 119±2 | TSF133 | 133 | 129±2 | TSF142 | 142 | 139±2 | TSF142E-1 | 142 | 139±2 | TSF157 | 157 | 152±2 | TSF172 | 172 | 169+1/-3 | TSF192 | 192 | 188+3/-1 | TSF216 | 216 | 214+1/-3 | TSF227 | 227 | 226+1/-3 | TSF240 | 240 | 237±2 | ||||||||||||||||||||||
| TRated = Rated Interrupting Temperature, TTrip Current = Cut-Off Temperature Range | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Approvals |
    |
|
| Terms of Delivery |
| Minimum order quantity: 1 PKU = 10 pieces |
|
| Manufacturer |
| NEC http://www.nec-schott.co.jp |
|
