Skydeomskifter, SPDT PC, Horizontal
Varenummer:
136-117
Varekode: TS-13L-A2-2-R1-E-H
32 stk.
på lager
Skydeomskifter, SPDT PC, Horizontal
Features
| • With print or soldering connections which are sealed against dirt and fluxing agent • Washable using all conventional cleaning agents • Small dimensions • Suitable for use in applications with limited space |
 |
| Technical Specifications |
|
|
| Switching Capacity: | 0,4VA at 20V AC or DC |
| Switching Cycle Under Load: | 30.000 |
| Contact Resistance: | 10mOhm |
| Insulation Resistance, Min.: | 1000MOhm |
| Dilelectric Strength: | 1000Veff |
| Operating Temperature: | -30...+85°C |
| Contacts: | Brass, Gold-plated Over Nickel |
| Terminals: | Brass, Gold-plated Over Nickel |
| Sealing: | Epoxy |
| Operations: | Nylon |
| Shell Material: | Diallylphthalate (DAP) |
|
|
Produktfiler
