Fiber Optic Rec. Diode 3μA/10μW + Hous.
Varenummer:
107-846
Varekode: SFH250V
Vægt: 3 g
0 stk.
på lager
Gruppe:
X6443
AVAGO TECHNOLOGIES Fiber Optic Receiving Elements
Series: SFH_V
AVAGO TECHNOLOGIES Fiber Optic Receiving Elements
Series: SFH_V
| Technical Specifications |
| Receiver photodiode resp. -transistor with plastic conector housing, mounting screw included 2,2mm aperture holds standard 1000micron plastic fiber No fiber stripping required Interference-free transmission from light-tight housing Good linearity No cross talk Operating temperature range -40...+85C |
 |
| Part Nr. | IS | @ | Pin | WLS | tr | tf |
| [µA] | [µW] | [nm] | [µs] | [µs] | ||
| SFH250V | 3 | 10 | 850 | 0,01 | 0,01 | |
| IS = Light Current, Pin = Input Power From Fiber, WLS = Wavelength Of Peak Sensitivity, tr = Typ. Rise Time, tf = Typ. Fall Time | ||||||
| ||||||
| Terms of Delivery |
| Minimum order quantity: please see price list column "MOQ". |
|
| Manufacturer |
| Avago http://www.avagotech.com |
|
