SMD-LED Red 33-60lm 110° D:8mm

Name: SMD-LED Red 33-60lm 110° D:8mm
SKU: 107539
Price: 27.89 DKK
Availability: OutOfStock

Varenummer: 107-539

Varekode: EHPAX08B/SUR01P1

0 stk. på lager

Technical Specifications


EHPAX_	Colour	WL	VA	LP	@I_F	U_F
		[nm]	[°]	[lm]	[mA]	[V]
08B/SUR01P1	Red	630...620	110	33...60	350	2,05...2,95
08B/UY01P1	Yellow	595...585	110	33...52	350	2,05...2,95
08B/SUG01P1	Green	535...520	100	45...70	350	3,25...4,15
08B/UB01P1	Blue	470...455	100	10...20	350	3,25...4,15
08B/DT01P1	White	-	120	45...70	350	3,25...4,15
08B/LM01P1	Warm White	-	120	33...52	350	3,25...4,15
WL = Peak Emission Wavelength, VA = Viewing Angle, LP = Typ. Luminous Power, I_F = Forward Current, U_F = Forward Voltage

Manufacturer

http://www.everlight.com

Inkl. moms

v/5 Kr. 27,89

Produktfiler

107-539

/ EHPAX08B/SUR01P1

0 stk. på lager

Technical Specifications


EHPAX_	Colour	WL	VA	LP	@I_F	U_F
		[nm]	[°]	[lm]	[mA]	[V]
08B/SUR01P1	Red	630...620	110	33...60	350	2,05...2,95
08B/UY01P1	Yellow	595...585	110	33...52	350	2,05...2,95
08B/SUG01P1	Green	535...520	100	45...70	350	3,25...4,15
08B/UB01P1	Blue	470...455	100	10...20	350	3,25...4,15
08B/DT01P1	White	-	120	45...70	350	3,25...4,15
08B/LM01P1	Warm White	-	120	33...52	350	3,25...4,15
WL = Peak Emission Wavelength, VA = Viewing Angle, LP = Typ. Luminous Power, I_F = Forward Current, U_F = Forward Voltage

Manufacturer

http://www.everlight.com
