SMD Clock Crystal 32,768kHz 20ppm

Varenummer: 103-319
Varekode: MC306-32,768
Vægt: 0 g
0 stk. på lager
Vis lignende produkter i kategorien "Ur quarz"
Technical Specifications
Frequency:
 32.768KHz
Frequency Tolerance (TU = 25°C):
 ±20ppm
Temperature Coefficient, Max.:
 -0,04ppm/°C2
Operating Temperature:
 -40...+85°C
Storage Temperature:
 -55...+125°C
Insulation Resistance, Min.:
 500MW
Drive Level, Max.:
 1,0μW
Shunt Capacitance, Typ.:
 0,85pF
Series Resistance, Max.:
 50kW
Aging (TU = 25°C), Max.:
 ±3ppm/Year
Shock Resistance, Max.:
 ±5ppm
Manufacturer

http://www.epson-electronics.de
Inkl. moms
Kr. 17,55
  • v/10 – Kr. 10,97
  • v/25 – Kr. 6,58
  • v/100 – Kr. 4,39
