  5. Clock Crystal 32,768kHz 2x6mm 15ppm

Clock Crystal 32,768kHz 2x6mm 15ppm

Varenummer: 103-317
Varekode: DT26K32,768
Vægt: 0 g
2 stk. på lager
Vis lignende produkter i kategorien "Ur quarz"
Technical Specifications
Frequency:
 32.768KHz
Frequency Tolerance (TU = 25°C)
DT26K32,768:
 ±15ppm
DT38K32,768:
 ±10ppm
Operating Temperature:
 -10...+60°C
Storage Temperature:
 -20...+70°C
Insulation Resistance, Min.:
 500MW
Drive Level, Max.:
 1,0μW
Shunt Capacitance, Max.
 1,3pF±0,3pF
Load Capacitance
DT26K32,768:
 12,5pF
DT38K32,768:
 12,5pF
Manufacturer
Abundance
http://www.aeccrystal.com
Inkl. moms
Kr. 7,05
  • v/10 – Kr. 4,41
  • v/25 – Kr. 2,64
  • v/100 – Kr. 1,76
Produktfiler
