Thermostats 145°C 2,5A

Varenummer: 93-260
Varekode: TUP62-145
Vægt: 26 g
3 stk. på lager
Bestil nu for afsendelse mandag d. 19/10
Vis lignende produkter i kategorien "Radiale"
Features
• For applications where a fixed temperature should not be exceeded and automatic restarting after the switch has cooled is desired.
Technical Specifications
Contact:
 NC
Housing:
 PBT
Switch-off Tolerance:
 ±5K
Standard Differential:
 30 ±15K
Rated Voltage:
 250V
Rated Current:
 2,5A
Long Terminal Wires:
 100mm
Insulation Class:
 IP00
Insulation Resistance:
 100MW
High Voltage Insulation:
 2,5kV
Approvals

Approval Standards:
 UL-873
Approved as:
 Thermostat
Switching Power:
 125V AC/4A (Resistive)
Temperature, Max.:
 140°C
Max. Cycles:
 6000

Approved Standards:
 CSA C22.2 No.24-1987
Approved as:
 Thermostat
Switching Power:
 125V AC/4A (Resistive)
Temperature, Max.:
 140°C
Max. Cycles:
 6000

Approved Standards:
 EN60730-1 / EN60730-2-9
Approved as:
 Thermal-Cut-Out
Switching Power:
 250V AC/2,5(1,6)A
Temperature, Max.:
 150°C
Max. Cycles:
 10000

Approved Standards:
 EN60730-1 / EN60730-2-2
Approved as:
 Thermal-Motor-Protector
Switching Power:
 250V AC
Temperature, Max.:
 150°C
Manufacturer
Uchiya
http://www.uchiya.ie
Inkl. moms
Kr. 65,16
  • v/10 – Kr. 39,09
  • v/25 – Kr. 26,06
  • v/100 – Kr. 19,55
