LCD-Graphicm 96,0x61,0mm 240x128 White D
Varenummer:
92-440
Varekode: EADIP240J-7KLW
Vægt: 120 g
0 stk.
på lager
Ved bestilling nu, får vi dem hjem lørdag d. 31/10
Gruppe:
W6260
ELECTRONIC ASSEMBLY LCD-Graphic-Modules FSTN Monochrome With Backlight DIP/DIL
Series: EA(E)DIP_LW
Background: White
Pixels: Black
ELECTRONIC ASSEMBLY LCD-Graphic-Modules FSTN Monochrome With Backlight DIP/DIL
Series: EA(E)DIP_LW
Background: White
Pixels: Black
| Technical Specifications |
| High contrast LCD-FSTN display White LED backlight Interface for 8-Bit data bus (EAE-Types RS232/I²C/SPI) Plug-in easily to a socket connector or solder directly into a PCB Supply voltage, typ. +3,3V resp. 5,0V Operating temperature range -20...+70C |
 |
| EA(E)DIP_ | Type | Format | V-Area | LxWxD |
| [HxV] | [mm] | [mm] | ||
| 128J-6N5_ | FSTN | 128x64 | 61,0x38,0 | 75x45,8x10,8 |
| 128W-6_ | FSTN | 128x64 | 63,5x35,0 | 71,4x54,6x12,1 |
| 160W-7_ | FSTN | 160x104 | 74,0x45,9 | 81,5x67,5x12,1 |
| 240J-7K_ | FSTN | 240x128 | 96,0x61,0 | 113x70x10,8 |
| 240J-7_ | FSTN | 240x128 | 96,0x60,4 | 113x70x10,8 |
| FSTN = Film Super Twisted Nematic, H = Horizontal (Pixel), V = Vertical (Pixel), V-Area = Viewing Area | ||||
| ||||
| EA(E)DIP_ | P-Size | Backl | B-Colour | Tamb |
| [mm] | [C] | |||
| 128J-6N5_ | 0,42x0,50 | LED | White | -20...+70 |
| 128W-6_ | 0,46x0,50 | LED | White | -20...+70 |
| 160W-7_ | 0,42x0,40 | LED | White | -20...+70 |
| 240J-7K_ | 0,35x0,41 | LED | White | -20...+70 |
| 240J-7_ | 0,35x0,41 | LED | White | -20...+70 |
| P-Size = Pixel Size, Backl = Backlight, B-Colour = Backlight Colour, Tamb = Ambient Operating Temperature | ||||
| ||||
| Note |
| You will find suitable mounting bezels for LCD graphic modules from ELECTRONIC ASSEMBLY in product group W6268. You will find suitable development tools for LCD graphic modules from ELECTRONIC ASSEMBLY in product group W6269. |
|
| Terms of Delivery |
| Minimum order quantity: please see price list column "MOQ". |
|
| Manufacturer |
 |
| http://www.lcd-module.de |
|
Inkl. moms
Kr. 1757,04
