Photointerr. Slot 5,0mm PCB-Mt

Name: Photointerr. Slot 5,0mm PCB-Mt
SKU: 92382
Price: 7.74 DKK
Availability: OutOfStock

Varenummer: 92-382

Varekode: ELITR9608

0 stk. på lager

Technical Specifications


Part Nr.	Gap	SW	U_F	@I_F	t_r	t_f
	[nm]	[mm]	[V]	[mA]	[μs]	[μs]
ELITR8102	3,1	1,0	1,6	20	20	20
ELITR9608	5,0	0,8	1,5	20	15	15
ELITR9702	5,0	0,5	1,5	20	15	15
ELITR9809	5,0	0,5	1,5	20	15	15
ELITR20403	3,0	0,4	1,6	20	15	15
SW = Slit Width, U_F = Max. Forward Voltage, I_F = Forward Current, t_r = Typ. Rise Time, t_f = Typ. Fall Time

Manufacturer

http://www.everlight.com

Inkl. moms

Kr. 7,74

Produktfiler

92-382

/ ELITR9608

0 stk. på lager

Technical Specifications


Part Nr.	Gap	SW	U_F	@I_F	t_r	t_f
	[nm]	[mm]	[V]	[mA]	[μs]	[μs]
ELITR8102	3,1	1,0	1,6	20	20	20
ELITR9608	5,0	0,8	1,5	20	15	15
ELITR9702	5,0	0,5	1,5	20	15	15
ELITR9809	5,0	0,5	1,5	20	15	15
ELITR20403	3,0	0,4	1,6	20	15	15
SW = Slit Width, U_F = Max. Forward Voltage, I_F = Forward Current, t_r = Typ. Rise Time, t_f = Typ. Fall Time

Manufacturer

http://www.everlight.com
