Bridge Rect. 35A 140V(RMS) Flat
Varenummer:
92-198
Varekode: FB3502
Vægt: 15 g
30 stk.
på lager
Gruppe:
V7636
FAGOR ELECTRONICA (FAG) Power Bridge Rectifiers 35A
Glass Passivated
Series: FB35_
Case: Epoxy with Cooling Plate
FAGOR ELECTRONICA (FAG) Power Bridge Rectifiers 35A
Glass Passivated
Series: FB35_
Case: Epoxy with Cooling Plate
| Technical Specifications |
| Thermal resistance, typical 1,3K/W Operating temperature range -55...+150C |
 |
| Part Nr. | URRM | URMS | UF | IF(AV) | IR |
| [V] | [V] | [V] | [A] | [µA] | |
| FB3501_ | 100 | 70 | 1,1 | 35 | 5 |
| FB3502_ | 200 | 140 | 1,1 | 35 | 5 |
| FB3506_ | 600 | 420 | 1.1 | 35 | 5 |
| FB3510_ | 1000 | 700 | 1,1 | 35 | 5 |
| URRM = Max. Peak Recurrent Reverse Voltage, URMS = Max. RMS Voltage, UF = Max. Forward Voltage, IF(AV) = Max. Average Forward Rectified Current, IR = Max. Reverse Current | |||||
| |||||
| Note |
| You will find suitable snap-on contacts in our blue "Passive and Electromechanical Components" catalogue at product group F1315. |
|
| Approvals |
 E130180 |
|
| Terms of Delivery |
| Minimum order quantity: please see price list column "MOQ". |
|
| Manufacturer |
 |
| http://www.fagorelectronica.com |
|
