N-Ch 30V 210A 230W 0,0028R TO220AB

Varenummer: 92-051
Varekode: IRF3703PBF
Vægt: 2 g
11 stk. på lager
Bestil inden kl. 14 i dag for afsendelse i dag
Yderligere 100 stk. kan skaffes søndag d. 1/11
Vis lignende produkter i kategorien "MOSFET"
Specifikationer
Komponenthus TO220
Transistor polaritet N-Ch
Produkt MOSFET
Drain-Source spænding, max 30  V
Effekt, max. 230  W
Continuous drain current, max 210  A
Drain-Source On-modstand, Rds(on) 0.0028  Ω
Gruppe: U8324
INTERNATIONAL RECTIFIER (IR) Power MOSFETs
Series: IRF_, IRL_
Case: TO220AB
Technical Specifications
Part Nr.
UDS
ID25
RDS(on)
UGS(th)
td(on)
td(off)
 [V]
[A]
W
[V]
[ns]
[ns]
IRF520NPBF100
9,7
0,200
2,0
4,5
32
IRF530NPBF100
17
0,090
2,0
9,2
35
IRF540NPBF100
33
0,044
2,0
11
39
IRF540ZPBF100
36
0,0265
2,0
15
43
IRF630NPBF200
9,3
0,300
2,0
7,9
27
IRF640NPBF200
18
0,150
2,0
10
23
IRF9Z34NPBF55
19
0,100
2,0
13
30
IRF1010NPBF55
85
0,011
2,0
13
39
IRF1010ZPBF55
75
0,0075
2,0
18
36
IRF1018EPBF60
79
0,0084
2,0
13
55
IRF1310NPBF100
42
0,036
2,0
11
45
IRF1404PBF40
202
0,004
2,0
17
46
IRF1404ZPBF40
75
0,0037
2,0
18
36
IRF1405PBF55
169
0,0053
2,0
13
130
IRF2804PBF40
75
0,002
2,0
13
130
IRF2807PBF75
82
0,013
2,0
13
49
IRF2903ZPBF30
75
0,0024
2,0
24
48
IRF3205PBF55
110
0,008
2,0
14
50
IRF3205ZPBF55
75
0,0065
2,0
18
45
IRF3415PBF150
43
0,042
2,0
12
71
IRF3703PBF30
210
0,0028
2,0
18
53
IRF3704ZPBF20
67
0,0079
1,65
8,9
11
IRF3708PBF30
62
0,012
0,6
7,2
17,6
IRF3709ZPBF30
87
0,0063
1,35
13
16
IRF3710PBF100
57
0,023
2,0
12
45
IRF3710ZPBF100
59
0,018
2,0
17
41
IRF3711ZPBF20
92
0,006
1,55
12
15
IRF3808PBF75
140
0,007
2,0
16
68
Part Nr.
UDS
ID25
RDS(on)
UGS(th)
td(on)
td(off)
 [V]
[A]
W
[V]
[ns]
[ns]
IRF4104PBF40
75
0,0055
2,0
16
38
IRF4905PBF55
74
0,020
2,0
18
61
IRF5210PBF100
40
0,060
2,0
17
79
IRF5305PBF55
31
0,060
2,0
14
39
IRF9520NPBF100
6,8
0,480
2,0
14
28
IRF9530NPBF100
14
0,200
2,0
15
45
IRF9540NPBF100
23
0,117
2,0
15
51
IRFB260NPBF200
56
0,040
2,0
17
52
IRFB3006PBF60
195
0,0025
2,0
16
118
IRFB3077PBF75
210
0,0033
2,0
25
69
IRFB31N20DPBF200
31
0,082
3,0
16
26
IRFB3206PBF60
75
0,003
2,0
19
55
IRFB3207ZPBF75
75
0,0041
2,0
20
55
IRF3306BPBF60
75
0,0042
2,0
15
40
IRFB3307ZPBF75
75
0,0058
2,0
15
38
IRFB3607PBF75
80
0,009
2,0
16
43
IRFB3806PBF60
43
0,0158
2,0
6,3
49
IRFB38N20DPBF200
38
0,054
3,0
16
29
IRFB4019PBF150
17
0,095
3,0
7
12
IRFB4020PBF200
18
0,100
3,0
7,8
16
IRFB4103PBF200
17
0,165
3,0
9,6
16
IRFB4110PBF100
180
0,0045
2,0
25
78
IRFB4115PBF150
104
0,011
3,0
18
41
IRFB41N15DPBF150
41
0,045
3,0
16
25
IRFB4127PBF200
76
0,020
3,0
17
56
IRFB4212PBF100
18
0,0725
3,0
7,7
14
IRFB4227PBF200
65
0,024
3,0
33
21
IRFB4229PBF250
46
0,046
3,0
18
30
IRFB4310ZPBF100
75
0,006
2,0
20
55
IRFB4321PBF150
83
0,015
3,0
18
25
Part Nr.
UDS
ID25
RDS(on)
UGS(th)
td(on)
td(off)
 [V]
[A]
W
[V]
[ns]
[ns]
IRFB4332PBF250
60
0,033
3,0
-
-
IRFB4410ZPBF100
97
0,009
2,0
16
43
IRFB4610PBF100
73
0,014
2,0
18
53
IRFB4615PBF150
35
0,039
3,0
15
25
IRFB4620PBF200
25
0,0725
3,0
13,4
25,4
IRFB4710PBF100
75
0,014
3,5
35
41
IRFZ24NPBF55
17
0,070
2,0
4,9
19
IRFZ34NPBF55
29
0,040
2,0
7
31
IRFZ44EPBF60
48
0,023
2,0
12
70
IRFZ44NPBF55
49
0,0175
2,0
12
44
IRFZ44ZPBF55
51
0,0139
2,0
14
33
IRFZ46NPBF55
53
0,0165
2,0
14
52
IRFZ48NPBF55
64
0,014
2,0
12
34
IRFZ48ZPBF55
61
0,011
2,0
15
35
IRL530NPBF100
17
0,100
1,0
7,2
30
IRL540NPBF100
36
0,044
1,0
11
39
IRL1004PBF40
130
0,0065
1,0
16
25
IRL1404PBF40
160
0,004
1,0
18
38
IRL1404ZPBF40
75
0,0031
1,4
19
30
IRL2203PBF30
116
0,007
1,0
11
23
IRL3103PBF30
64
0,012
1,0
8,9
14
IRL3705NPBF55
89
0,010
1,0
12
37
IRL3714ZPBF20
36
0,016
1,65
6
10
IRL3715ZPBF20
50
0,011
1,65
7,1
11
IRL3803PBF30
140
0,006
1,0
14
29
IRL7833PBF30
150
0,0038
1,4
18
21
IRL8113PBF30
105
0,006
1,35
14
18
IRLZ24NPBF55
18
0,060
1,0
7,1
20
IRLZ34NPBF55
30
0,035
1,0
8,9
21
IRLZ44NPBF55
47
0,022
1,0
11
26
UDS = Max. Drain-Source Voltage, ID25 = Max. Continuous Drain Current At TC = 25C, RDS(on) = Max. Drain-Source On-Resistance, UGS(th) = Min. Gate Threshold Voltage, td(on) = Turn-On Delay Time, td(off) = Turn-Off Delay Time, TC = Case Temperature
Note
You will find suitable MOSFET Driver ICs in this catalogue starting at product group B1633. Suitable isolation assemblies and heatsinks can be found in our blue "Passive and Electromechanical Components" catalogue starting at product group G9111. Thermolubricants are available in the red "Components and Devices" catalogue from product group R3211.
Terms of Delivery
Minimum order quantity: Please see price list column "MOQ".
Manufacturer

http://www.irf.com
Inkl. moms
Kr. 51,24
  • v/10 – Kr. 42,49
  • v/25 – Kr. 31,87
  • v/100 – Kr. 26,55
  • v/1000 – Kr. 21,24
