Soldering Station
Varenummer:
91-060
Varekode: LA142201
Vægt: 13015 g
0 stk.
på lager
Gruppe:
T3711
GIE-TEC Soldering Station
Series: LA
GIE-TEC Soldering Station
Series: LA
| Application |
| This soldering machine from Gie-Tec is based on the stationary soldering bath principle which makes use of a small volume of soldering and needs only a short populated circuit board. Simply and effortlessly connecting lugs, coils and transformers as well as electronic components can be tinned. |
 |
| Features |
| • Anodized aluminium housing (LxWxH) 295x260x140mm • Heater plate 230V/2000W, adjustable control • Aluminium soldering tray with stainless steel lining 235x205x13mm • Only requires about 4,5kg of soldering • Bimetal clock thermometer (50° to 300°C) • Soldering bogie with adjustable inner rails, max. board size 180x180mm • Short heating time • Operating method based on the stationary soldering bath |
|
| Note |
| You will find suitable soldering bars at product group R5511. |
|
| Terms of Delivery |
| Minimum order quantity: 1 PKU = 1 piece |
|
| Manufacturer |
 |
| http://www.gie-tec.de |
|
