Lead-Acid Rech. Battery 12V/12 Ah VdS
Varenummer:
89-655
Varekode: NP12-12
Vægt: 5150 g
1 stk.
på lager
Specifikationer
| Batterikapacitet | 12 Ah |
|---|---|
| Spænding | 12 V |
Gruppe:
S2752
YUASA Lead-Acid Rechargeable Batteries
Rated Voltage: 12V
Series: NP
YUASA Lead-Acid Rechargeable Batteries
Rated Voltage: 12V
Series: NP
| Application |
| Uninterruptible power supplies (UPS), emergency lighting, photovoltaic applications, testing equipment and measuring devices. |
 |
| Features |
| Service-free operation Very good charging efficiency Expected Design Life: 3 to 5 years Good cycle durability according to discharge intensity, more than 1000 discharging/recharging cycles Extended shelf life at low self-discharge level Valve regulated design Absorbing GlassMatt technology in which the electrolyte is fully absorbed (AGM = Absorbing GlassMatt Technology) Mechanically strong ABS container, extremely flame-retardant according to UL94HB Continuous operation in a lateral position possible Corrosion reduction using a lead-tin-calcium alloy to extend service life Excellent high current performance |
|
| Technical Specifications |
| Part Nr. | UN | CN | C10 | Weight |
| [V] | [Ah] | [Ah] | [kg] | |
| NP0.8-12 | 12 | 0,8 | 0,7 | 0,35 |
| NP1.2-12 | 12 | 1,2 | 1,1 | 0,57 |
| NP2.0-12 | 12 | 2 | 1,8 | 0,70 |
| NP2.3-12 | 12 | 2,3 | 2,1 | 0,94 |
| NP4-12 | 12 | 4 | 3,7 | 1,70 |
| NP7-12 | 12 | 7 | 6,5 | 2,65 |
| NP12-12 | 12 | 12 | 11,2 | 4,09 |
| NP17-12 | 12 | 17 | 14,0 | 5,97 |
| NP24-12 | 12 | 24 | 22,3 | 8,92 |
| NP38-12 | 12 | 38 | 35,4 | 13,93 |
| NP65-12 | 12 | 65 | 60,5 | 22,82 |
| UN = Rated Voltage, CN = Rated Capacitance, Discharging in 20h up to 1,75V/Cell, C10 = Discharging in 10h up to 1,75V/Cell | ||||
| ||||
| Dimensions |
| Part Nr. | L | W | H | Layout | Terminal |
| [mm] | [mm] | [mm] | |||
| NP0.8-12 | 96 | 25 | 61,5 | 7 | E |
| NP1.2-12 | 97 | 48 | 54,5 | 3 | A |
| NP2.0-12 | 150 | 20 | 89 | 8 | B |
| NP2.3-12 | 178 | 34 | 64 | 1 | A |
| NP4-12 | 90 | 70 | 106 | 1 | A |
| NP7-12 | 151 | 65 | 97,5 | 4 | A |
| NP12-12 | 151 | 98 | 97,5 | 4 | D |
| NP17-12 | 181 | 76 | 167 | 2 | C |
| NP24-12 | 166 | 175 | 125 | 2 | C |
| NP38-12 | 197 | 165 | 170 | 2 | C |
| NP65-12 | 350 | 166 | 174 | 2 | C |
| |||||
| Charging Methods |
| The valve-regulated Yuasa batteries should only be charged at a constant voltage with a current limitation of 0,1CA to max. 0,25CA. |
|
| Trickle Charge |
| Constant charging voltage of 2,275V/cell at 20C. |
|
| Cycle Use |
| Constant voltage charging at 2,45 ... 2,5V/cell at 20C, charging time 20h max. |
|
| Recommended Cut-Off Voltage |
| ||
| Discharge Current | Cut-Off Voltage | |
| [CA] | [V/Cell] | |
| 0,10 | 1,75 | |
| 0,17 | 1,70 | |
| 0,26 | 1,67 | |
| 0,60 | 1,60 | |
| 3,00 | 1,301) | |
| 1) Depth of Discharge Detrimental to Service Life | ||
| ||
| Service Life Expectancy |
| The expected operating service life of the NP series is 3 to 5 years. This can be achieved under optimal operating conditions if a permanent battery temperature of 20C is maintained. The battery with a float charge voltage of 2,275V/cell is charged and one of the local constant charging currents does not cross the effective ripple current value of 0,1CA. |
|
| Approvals |
| NP1,2-12, NP2,3-12, NP7-12, NP12-12, NP17-12, NP24-12, NP38-12, NP65-12:VdS |
|
tr>
| Approvals |
 924, Sheet MH 12970, 107 (Appliance in medical rooms) 108 (Emergency lighting) 0510/Part 2 (Evaporated to a negligible extent) 0833/Part 1 (Burglar alarm systems) |
|
| Note |
| You will find suitable battery chargers at product group S7811. On request, we will gladly send you the recommended charging circuit from the manufacturer. Prices exclude battery disposal fee, in accordance with BattG for deliveries within Germany to customers without ownership rights contract (see for price list). |
|
| Recycling |
| All used lead batteries must be given to an environmentally-friendly waste bank for disposal in accordance with local regulations. Do not dispose of used batteries in domestic waste!   |
|
Produktfiler
