CR2032 20,0x3,2mm. lodret 3V 230mAh
Varenummer:
89-539
Varekode: CR2032SLF
Vægt: 5 g
11 stk.
på lager
Bestil inden kl. 14 i dag for afsendelse i dag
Yderligere 2190 stk. kan skaffes søndag d. 1/11
| Technical Specifications |
| Part Nr. | IEC | UN | Ctyp. |
| [V] | [mAh] | ||
| CR2032_ | CR2032 | 3 | 230 |
| CR2430_ | CR2430 | 3 | 280 |
| CR2450PCB | CR2450 | 3 | 560 |
| CR2450PCB-3 | CR2450 | 3 | 560 |
| UN = Rated Voltage, Ctyp. = Capacitance, Typ., 20°C, End Voltage 2,0V | |||
 | |||
| Dimensions |
| |
| Material Strength of Solder Pin: | 0,15mm |
| |
| Part Nr. | A | D | E | F | G | H | K |
| [mm] | [mm] | [mm] | [mm] | [mm] | [mm] | [mm] | |
| CR2032SLF | 21,5 | 1 | 4,2 | 20,5 | - | 1 | - |
| CR2032PCB | 20,0 | 11 | 3,2 | 17,8 | 7,5 | 10 | 11,4 |
| CR2430SLF | 25,8 | 1 | 4,0 | 25,0 | - | 1 | - |
| CR2430PCB | 24,5 | 11 | 3,0 | 17,8 | 7,5 | 10 | 11,4 |
| CR2450PCB | 24,7 | 12,7 | 5,0 | 17,8 | 7,5 | 10 | 11,4 |
| CR2450PCB-3 | 24,7 | 13,2 | 5,0 | 17,8 | 7,5 | 10 | 11,4 |
| C = 10mm | |||||||
| |||||||
| Note |
| • Prices exclude battery disposal fee, in accordance with BattG for deliveries within Germany to customers without ownership rights contract (see for price list). • Please note the information concerning limited shipping of dangerous goods. • Batteries are outside the scope of the RoHS. However, the soldering pins meet RoHS specifications. |
|
| Recycling |
| All used batteries or cells must be given to an environmentally-friendly waste bank for disposal in accordance with local regulations. Do not dispose of used batteries in domestic waste!   |
|
| Terms of Delivery |
| Minimum order quantity: 1 PKU = 5 pieces |
|
| Manufacturer |
 |
| http://www.varta-microbattery.com |
|
