SMD Tact Switch Horizontal 13mm 1,6N
Switching Contact, Max.: 12V DC
Switching Current, Max.: 50mA
Test Voltage, 1min.: 250V AC
Operating Life with Switching Capacity: 200.000 Operations
Contact Resistance, Max.: 100mW
Insulation Resistance, Min.: 100MW/500V DC
Switching Type: 1 NO Contact
Operating Force: 1,6N
Operating Path: 0,25mm +0,2, -0,1
Insulation Material: Thermoplastic Nylon, UL94V-0
Contact Surface: Bronze with Silver Cladding
Soldering Temperature, Max.: 255°C
Operating Temperature: -25...+70°C
hEIGHT: 13mm
Stem Height: 9.5 mm
- v/10 – Kr. 3,75
- v/25 – Kr. 3,00
- v/100 – Kr. 2,00
- v/1000 – Kr. 1,50
