SMD Female Header 1R Straight 1x40-Pole
Varenummer:
88-200
Varekode: BL1X40Z-SMD
Vægt: 4 g
0 stk.
på lager
| Features |
| • Tin-plated design • Suitable for square pins 0,635x0,635mm (1/40 ") |
 |
| Technical Specifications |
| |
| Insulation Shell: | Thermoplastic, UL94V-0 |
| Contact Material: | Phosphor-Bronze |
| Contact Surface: | Tin-plated |
| Contact Resistance: | £20mW |
| Rated Voltage: | 250VRMS/250V DC |
| Dielectric Strength (1Min.): | 1000V AC |
| Rated Current: | 3A |
| Temperature Range: | -40...+150°C |
| |
| Terms of Delivery |
| Minimum order quantity: 1 PKU = 5 pieces |
|
| Manufacturer |
 |
| http://www.mpegarry.de |
|
