SMD Pin Header 80-Pole Straight 2R Au
Varenummer:
88-158
Varekode: ASL80MG-SMD
Vægt: 5 g
38 stk.
på lager
Gruppe: F2329
MPE GARRY SMD Pin Header
Series: WSL_-SMD
Double Row, Straight
Pitch: 2,54mm
MPE GARRY SMD Pin Header
Series: WSL_-SMD
Double Row, Straight
Pitch: 2,54mm
| Features |
| • Suitable for SMD assembly • Flash gold design • Arbitrary mounting |
 |
| Technical Specifications |
| |
| Insulation Shell: | Thermoplastic, UL94V-0 |
| Contact Material: | Copper alloy |
| Contact Surface: | Au-plated |
| Rated Current: | 3,0A |
| Rated Voltage: | 250VRMS/V DC |
| Dielectric Strength (1Min.): | 500VRMS |
| Temperature Range: | -40...+105°C |
| Short Term (10s): | +260°C |
| |
| Terms of Delivery |
| Minimum order quantity: 1 PKU = 10 pieces |
|
| Manufacturer |
 |
| http://www.mpegarry.de |
|
