Box Header 5,0 Hor. 4-Pole Closed End
Varenummer:
87-655
Varekode: STL950WH4
Vægt: 1 g
16 stk.
på lager
STL950/..G-5.0-H-GREEN
- 4 poles
- Horizontal pin strip
- Spacing 5.0 mm
- Closed ends
| Wire Size | ||
|---|---|---|
| Solid | - - | |
| Stranded | - - | |
| Stranded with ferrule | - - | |
| Dimensions | ||
| PCB hole diameter | 1.4 mm | |
| Materials | ||
| Contact pin | Copper Alloy | |
| Insulating Material | ||
| Material | PA 6.6 | |
| Flammability class | UL 94 V-0 | |
| Temperatures | ||
| Operating temperature | -40 °C - 105 °C | |
| Store temperature | -40 °C - 105 °C | |
| Wave Soldering Process | Reflow Process | |
| Soldering temperature, recommended | 260 °C | - |
| Peak soldering time, recommended | 3-4 s | - |
