Series SBOX
Type Heat shrink tube
Colour black
Length of Shrink Tubing 8 m
Diameter: before shrinkage 6.4 mm
Diameter: after shrinkage 3.2 mm
Shrinkage rate 2:1
Minimum shrinkage temperature 120 °C
Flammability flame retardant IEC332.1
RoHS-Conform
Type
- Heat shrink tube
- SBOX
- 10390818
- G8631
- black
- Polyolefin
- dispenser box
- - Thin walled radiation-interlaced polyolefin
- Flame retardant, self-extinguishing
Dimensions and Weights
Length of Shrink Tubing- 8 m
- 6.4 mm
- 3.2 mm
- 0.64 mm
Operating conditions
Operating Temperature Min.- -55 °C
- 125 °C
Technical features
Shrinkage rate- 2:1
- 120 °C
- 20 kV/mm
Safety/Certifications
Approvals- UL 224
- flame retardant IEC332.1
