Transformer 5VA 230V 2x9V 2x278mA
Varenummer:
86-460
Varekode: MT609-2
Vægt: 193 g
2 stk.
på lager
Specifikationer
| Produkt | transformator |
|---|---|
| AC Effekt, max. | 5 VA |
| Sekundær | 2x9V |
| Strøm, max. (sekundærvikling) | 2x278mA |
| Primær | 230V |
Gruppe:
D7533
MYRRA Transformers
Core: EI42
Non Short-Circuit Proof
Output: 5VA
Input Voltage: 230V
MYRRA Transformers
Core: EI42
Non Short-Circuit Proof
Output: 5VA
Input Voltage: 230V
| Technical Specifications |
 | |
| Temperature Resistance Class: | T 50/B |
| Primary Voltage: | 230V (50/60Hz) |
| Rated Power1): | 5VA |
| Test Voltage: | 4kV |
| No-load Voltage: | 1,6 x UN sec |
| Recommended Fuse (Extern.,Primary): | 32mA |
| 1) Per Temperature Class | |
| |
| Note |
| You will find suitable fuses in this catalogue at product group E1441. Recommended drill-hole diameter for pins: 1,3mm, for attachments: 4mm |
|
| Approvals |
EN61558-1,  0570,  506     |
|
| Terms of Delivery |
| Minimum order quantity: 1 PKU = 1 piece |
|
| Manufacturer |
 |
| http://www.myrra.com |
|
Inkl. moms
Kr. 43,60
- v/10 – Kr. 36,33
- v/25 – Kr. 29,06
- v/100 – Kr. 26,16
