Line Filter PCB 3100 6,5A
Varenummer:
86-364
Varekode: FIL3100
Vægt: 42 g
0 stk.
på lager
Ved bestilling nu, får vi dem hjem mandag d. 2/11
Gruppe:
D3321
KEMET/ARCOTRONICS RFI Suppression Filters for PCB Mounting
In Plastic Housing
KEMET/ARCOTRONICS RFI Suppression Filters for PCB Mounting
In Plastic Housing
| Features |
| Compact design PVC housing with solder pins Universal application For currents up to 1A, 6A or 6,5A |
 |
| Technical Specifications |
| |
| Rated Voltage: | 250V, 50/60Hz |
| Dielectric Strength, 2s | |
| Line To Ground: | 3kV DC or 1,8kV AC |
| Line To Line: | 1,7kV DC |
| Operating Temperature: | -25...+85C |
| Climatic Category: | HPF (25/085/21) |
| |
| Part Nr. | IR | L | CX | CY | IL |
| [A] | [mH] | [µF] | [pF] | [mA] | |
| FIL3100 | 6,5 | 2x1 | 0,1 | 2x2500 | 2x0,23 |
| FIL5001 | 1 | 2x10 | 0,033 | 2x2500 | 2x0,23 |
| FIL5006 | 6 | 2x1 | 0,033 | 2x2500 | 2x0,23 |
| IR = Rated Current, at 40C, L = Inductance, IL = Leakage Current, Max. at 220V, 50Hz | |||||
| |||||
| Approvals |
FIL3100:  0565-3,   FIL500_: 0565-3 |
|
| Terms of Delivery |
| Minimum order quantity: 1 PKU = 1 piece |
|
| Manufacturer |
 |
| http://www.kemet.com |
|
