Ceramic Resonator 2-Pole 2,00MHz
Varenummer:
86-096
Varekode: ZTAWS2.00MG
Vægt: 0 g
0 stk.
på lager
Kontakt os for at få oplyst leveringstid
Gruppe: D9512
Ceramic Resonators
Series: ZTB, ZTA
Without Load Capacitance
Frequency: 455k...12MHz
Ceramic Resonators
Series: ZTB, ZTA
Without Load Capacitance
Frequency: 455k...12MHz
| Technical Specifications |
| Part Nr. | f | Tol. | TStab | Age |
| [MHz] | [%] | [%] | [%] | |
| ZTB455EB | 0,455 | ±2 | ±0,3 | ±0,5 |
| ZTA2.00MG | 2,00 | ±0,5 | ±0,3 | ±0,3 |
| ZTAWS2.00MG | 2,00 | ±0,5 | ±0,3 | ±0,3 |
| ZTA3.58MG | 3,58 | ±0,5 | ±0,3 | ±0,3 |
| ZTAWS3.58MG | 3,58 | ±0,5 | ±0,3 | ±0,3 |
| ZTAWS4.0MG | 4,00 | ±0,5 | ±0,3 | ±0,3 |
| ZTA12.00MT | 12,00 | ±0,5 | ±0,3 | ±0,3 |
| f = Frequency, Tol. = Frequency, TStab = Temperature Stability, -20...+80C, Age = Aging for 10 Years | ||||
 | ||||
| Part Nr. | Rres | Uwith | Riso |
| [W] | [V DC] | [W] | |
| ZTB455EB | 20 | - | - |
| ZTA2.00MG | 80 | 100 | 5x108 |
| ZTAWS2.00MG | 80 | 100 | 5x108 |
| ZTA3.58MG | 30 | 100 | 5x108 |
| ZTAWS3.58MG | 35 | 100 | 5x108 |
| ZTAWS4.0MG | 30 | 100 | 5x108 |
| ZTA12.00MT | 25 | 100 | 5x108 |
| Rres = Resonant Resistance, Uwith = Voltage Sustaining Capability, 5s, Riso = Insulation Resistance | |||
| |||
| Terms of Delivery |
| Minimum order quantity: 1 PKU = 50 pieces |
|
| Manufacturer |
| Various |
|
Inkl. moms
Kr. 8,30
- v/10 – Kr. 3,17
- v/25 – Kr. 1,52
- v/100 – Kr. 1,25
Produktfiler
