Oscillator 2,4576MHz DIL14 CMOS/TTL

Name: Oscillator 2,4576MHz DIL14 CMOS/TTL
SKU: 86085
Price: 21.25 DKK
Availability: InStock

Varenummer: 86-085

Varekode: QOM002,457

Vægt: 4 g

3 stk. på lager

Bestil nu for afsendelse i morgen

Yderligere 230 stk. kan skaffes lørdag d. 31/10

Vis lignende produkter i kategorien "Quarz oscillatorer"

Features

• Suitable for CMOS and TTL
• Consisting of piezoelectric resonator and oscillator circuit
• High reliability due to hermetically sealed metal housing

Technical Specifications



Frequency Range:	1,843MHz...64MHz
Frequency Stability:	±100ppm
Temperature Range:	0...+70°C
Storage Temperature:	-55...+125°C
Operating Voltage [V_DD]:	5^{± 0,5}V DC
Current Requirement, Max.
1,843...20MHz:	20mA
24...40MHz:	30mA
50...70MHz:	60mA
Symmetry at 50% V_DDtight:	45...55%
Output Voltage, Max.
"1"-Level:	+4,5V(90% V_DD)
"0"-Level:	+0,5V(10% V_DD)
Output Load:	15pF Typ. or 10 TTL Max.

Manufacturer

Abundance
http://www.aeccrystal.com

Inkl. moms

Kr. 21,25

v/10 – Kr. 19,69
v/25 – Kr. 16,41
v/100 – Kr. 13,12
