Crystal 4.194.304Hz HC-49/U

Varenummer: 85-984
Varekode: QM004,194
Vægt: 1 g
0 stk. på lager
Ved bestilling nu, får vi dem hjem søndag d. 1/11
Vis lignende produkter i kategorien "HC-49"
Technical Specifications
Temperature Range:
 -10...+60°C
Frequency Tolerance (25°C):
 ±30ppm
Shunt Capacitance, Max.:
 7pF
Drive Level:
 1,0mW
Insulation Resistance (100V DC):
 >500MW
Aging:
 ±5ppm/Year
Part Nr.
 Frequency
 C
 RESR
 Type
  [Hz]
 [pF]
 W

QM001,843 1.843.200
 30
 600
 Fundamental
QM002 2.000.000
 30
 550
 Fundamental
QM002,457 2.457.600
 30
 350
 Fundamental
QM003 3.000.000
 32
 150
 Fundamental
QM003,276 3.276.800
 12,5
 150
 Fundamental
QM003,579 3.579.545
 16
 100
 Fundamental
QM003,686 3.686.400
 16
 100
 Fundamental
QM004 4.000.000
 30
 90
 Fundamental
QM004,096 4.096.300
 30
 90
 Fundamental
QM004,194 4.194.304
 32
 90
 Fundamental
QM004,915 4.915.200
 16
 90
 Fundamental
QM005 5.000.000
 30
 80
 Fundamental
QM006 6.000.000
 30
 60
 Fundamental
QM006,144 6.144.000
 16
 60
 Fundamental
QM006,553 6.553.600
 30
 60
 Fundamental
QM007,372 7.372.800
 32
 60
 Fundamental
QM008 8.000.000
 30
 50
 Fundamental
QM009,216 9.216.000
 30
 45
 Fundamental
QM009,830 9.830.400
 30
 45
 Fundamental
QM010 10.000.000
 30
 40
 Fundamental
QM010,240 10.240.000
 30
 40
 Fundamental
QM010,700 10.700.000
 30
 40
 Fundamental
QM011,0592 11.059.200
 30
 40
 Fundamental
QM012 12.000.000
 30
 35
 Fundamental
QM014,318 14.318.180
 30
 35
 Fundamental
QM016 16.000.000
 30
 30
 Fundamental
QM018 18.000.000
 30
 25
 Fundamental
QM018,432 18.432.000
 30
 25
 Fundamental
QM020 20.000.000
 30
 25
 Fundamental
QM024-FUND 24.000.000
 30
 25
 Fundamental
QM027 27.000.000
 32
 50
 3. Harmonic
QM032 32.000.000
 *
 50
 3. Harmonic
QM036 36.000.000
 *
 50
 3. Harmonic
QM048 48.000.000
 *
 50
 3. Harmonic
C = Load Capacitance, RESR = Resistance of Series Resonance, Max., * = Infinitely
Manufacturer
Abundance
http://www.aeccrystal.com
Inkl. moms
Kr. 9,60
  • v/10 – Kr. 6,00
  • v/25 – Kr. 3,60
  • v/100 – Kr. 2,74
