NTC Thermistor 1,5K 10% B57164
Varenummer:
85-060
Varekode: K164NK001,5-10
Vægt: 0 g
105 stk.
på lager
Bestil inden kl. 14 i dag for afsendelse i dag
Yderligere 340 stk. kan skaffes tirsdag d. 10/11
Vis lignende produkter i kategorien "Disc (Standard)"
• Lacquer-coated thermistor disc
• 2,0mm lacquer-free from the lower rim of the disc
• Tinned copper leads
• Pitch 5,0mm |
 |
| • Temperature compensation, measurement and control |
|
|
| |
|
Climatic Category (IEC68-1): |
55/125/21 |
Power, Max. (25°C): |
450mW |
Resistance Tolerance: |
±10% |
Nominal Temperature: |
+25°C |
Temperature Range: |
-55...+125°C |
Dissipation Factor (in Air): |
Approx. 7,5mW/K |
Thermal Cooling Time Constant (in Air): |
Approx. 20s |
Heat Capacity: |
Approx. 150mJ/K |
|
| Labelling |
| Resistance value marked |
|
|
