Potentiometer 16/6 Mono Log 4K7
Varenummer:
84-984
Varekode: P162MGK004,7
Vægt: 9 g
9 stk.
på lager
Bestil inden kl. 14 i dag for afsendelse i dag
Vis lignende produkter i kategorien "Logaritmisk"
Electrical Specifications
|
 |
|
|
Rated Power (TU = 40°C):
|
0,12W
|
Operating Voltage, Max.:
|
350V DC
|
Insulation Voltage:
|
500V AC
|
Insulation Resistance:
|
³5GW
|
Resistance Tolerance
|
100W...1MW:
|
±20%
|
>1MW:
|
±30%
|
|
Mechanical Specifications
|
|
|
|
Rotation Angle (Mechanical):
|
300° ±5°
|
Operating Torque:
|
0,4...1,5Ncm
|
Permissible Torque at End Stop, Max.:
|
60Ncm
|
Weight, approx.:
|
6g
|
|
|
|
|
Plastic Spindle
|
Diameter (D):
|
6,0mm
|
Length (L):
|
50,0mm
|
Bush (C):
|
8,0mm
|
Spindle (A):
|
M10x0,75
|
Solder Tag Terminations:
|
5/5(10)mm
|
|
|
