Resistor 5W 5% 330R
Varenummer:
84-540
Varekode: RCIE330
Vægt: 2 g
15 stk.
på lager
Bestil nu for afsendelse i morgen
Yderligere 750 stk. kan skaffes søndag d. 1/11
Specifikationer
| Effekt, max. | 5 W |
|---|---|
| Modstand | 330 Ω |
| Komponenthus | 208-8 |
| Tolerance | ±10 % |
Gruppe: C1630
VITROHM Wirewound Power Ceramic Resistors
Series: KH208-8
Style: Bulk
Power: 5W
Tolerance: 10%
| Features |
| • Wound on a glass fiber core with special direct terminals, temperature resistant • Wound resistor embedded in a cement sealed ceramic tube |
 |
| Technical Specifications |
|
|||||||||||||||||||||||||||||||||
| Resistance Tolerance: | ±10% | Power Rating (70°C): | 5W | Operating Voltage, Max.: | (PxR)1/2 | Thermal Resistance: | 50K/W | Insulation Resistance: | >104 MW | Insulation Voltage (1Min.): | 2000Vrms | Temperature Coefficient | 0R075...0R3: | +400 ±50ppm/K | 0R33...470R: | 0 ±40ppm/K | 510R...15K: | 0 ±10ppm/K | Temperature Range: | -55...+350°C | Climatic Category: | 55/200/21 | Failure Rate (Value Dependent): | Approx. 100x10-9/h | Terminal Tensile Strength: | 50N | Solderability:1) | 2,5s | Derating: | Linear 70°C to 350°C (0W) | |||
| 1) Solderglobule Test, IEC 60068-2-20-T | |||||||||||||||||||||||||||||||||
|
|||||||||||||||||||||||||||||||||
| Note |
| • Please see product group C1110 for taped jumper wires and zero-ohm resistors. |
|
| Norms |
| Applicable: CECC40202-001, -005 |
|
| Labelling |
| Manufacturer logo, series, resistance value, tolerance |
|
| Terms of Delivery |
| Minimum order quantity: 1 PKU = 10 pieces Form of delivery: Bulk |
|
| Manufacturer |
 |
| http://www.vitrohm.de |
|
Inkl. moms
Kr. 6,25
- v/10 – Kr. 5,00
- v/100 – Kr. 3,75
- v/500 – Kr. 2,75
Produktfiler
