U-Reg -15V 0,1A SO8

Name: U-Reg -15V 0,1A SO8
SKU: 82006
Price: 9.35 DKK
Availability: OutOfStock

Varenummer: 82-006

Varekode: TS79L15CS

0 stk. på lager

Kontakt os for at få oplyst leveringstid

Vis lignende produkter i kategorien "SMD"

Technical Specifications


Part Nr.	U_in	I_out	U_out	Reg_line	Reg_load
	[V]	[A]	[V]	[mV]	[mV]
TS78L05CS	35	0,1	4,80...5,20	55	11
TS78L08CS	35	0,1	7,70...8,30	20	15
TS78L09CS	35	0,1	8,60...9,40	20	15
TS78L12CS	35	0,1	11,50...12,50	120	20
TS78L15CS	35	0,1	14,40...15,60	130	25
TS78L18CS	35	0,1	17,30...18,70	45	30
TS78L24CS	40	0,1	23,00...25,00	50	40
TS79L05CS	-35	0,1	-4,80...-5,20	-	-
TS79L09CS	-35	0,1	-8,60...-9,40	-	-
TS79L12CS	-35	0,1	-11,50...-12,50	-	-
TS79L15CS	-35	0,1	-14,40...-15,60	-	-
TS79L18CS	-35	0,1	-17,30...-18,70	-	-
TS79L24CS	-40	0,1	-23,00...-25,00	-	-
U_in = Max. Input Voltage, I_out = Max. Output Current, U_out = Output Voltage, Reg_line = Typ. Line Regulation, Reg_load = Typ. Load Regulation

Manufacturer

http://www.taiwansemi.com

Inkl. moms

Kr. 9,35

Produktfiler

82-006

/ TS79L15CS

0 stk. på lager

Kontakt os for at få oplyst leveringstid

Technical Specifications


Part Nr.	U_in	I_out	U_out	Reg_line	Reg_load
	[V]	[A]	[V]	[mV]	[mV]
TS78L05CS	35	0,1	4,80...5,20	55	11
TS78L08CS	35	0,1	7,70...8,30	20	15
TS78L09CS	35	0,1	8,60...9,40	20	15
TS78L12CS	35	0,1	11,50...12,50	120	20
TS78L15CS	35	0,1	14,40...15,60	130	25
TS78L18CS	35	0,1	17,30...18,70	45	30
TS78L24CS	40	0,1	23,00...25,00	50	40
TS79L05CS	-35	0,1	-4,80...-5,20	-	-
TS79L09CS	-35	0,1	-8,60...-9,40	-	-
TS79L12CS	-35	0,1	-11,50...-12,50	-	-
TS79L15CS	-35	0,1	-14,40...-15,60	-	-
TS79L18CS	-35	0,1	-17,30...-18,70	-	-
TS79L24CS	-40	0,1	-23,00...-25,00	-	-
U_in = Max. Input Voltage, I_out = Max. Output Current, U_out = Output Voltage, Reg_line = Typ. Line Regulation, Reg_load = Typ. Load Regulation

Manufacturer

http://www.taiwansemi.com
