Pr. Sensor Comp 200kPa +-1,0% C344B
Varenummer:
81-834
Varekode: MPX2200AP
Vægt: 22 g
0 stk.
på lager
Kontakt os for at få oplyst leveringstid
- IC, SENSOR, ABS PRESS 29PSI, 344B-4
- Pressure Type: Absolute
- Operating Pressure Range: 0 to 200kPa
- Sensitivity, V/P: 0.2mV/kPa
- Supply Current: 6mA
- Sensor Case Style: 344B-01
- No. of Pins: 4
- Supply Voltage Range: 16V
- Operating Temperature Range: -40°C to +125°C
- SVHC: No SVHC (19-Dec-2011)
- Base Number: 2200
- Connection Size: 4.93mm
- Operating Pressure Range: 0kPa to 200kPa
- Operating Temperature Max: 125°C
- Operating Temperature Min: -40°C
- Package / Case: 344B-01
- Port Style: Single Port
- Supply Voltage Max: 16V
- Supply Voltage Min: 10V
- Termination Type: Through Hole
Pr. Sensor Comp 200kPa +-1,0% C344B
81-834
/ MPX2200AP
0 stk.
på lager
Kontakt os for at få oplyst leveringstid
- IC, SENSOR, ABS PRESS 29PSI, 344B-4
- Pressure Type: Absolute
- Operating Pressure Range: 0 to 200kPa
- Sensitivity, V/P: 0.2mV/kPa
- Supply Current: 6mA
- Sensor Case Style: 344B-01
- No. of Pins: 4
- Supply Voltage Range: 16V
- Operating Temperature Range: -40°C to +125°C
- SVHC: No SVHC (19-Dec-2011)
- Base Number: 2200
- Connection Size: 4.93mm
- Operating Pressure Range: 0kPa to 200kPa
- Operating Temperature Max: 125°C
- Operating Temperature Min: -40°C
- Package / Case: 344B-01
- Port Style: Single Port
- Supply Voltage Max: 16V
- Supply Voltage Min: 10V
- Termination Type: Through Hole
