Optoc-Darl. >2,5kV 7V 60mA DIP8
Varenummer:
79-049
Varekode: 6N138
Vægt: 0 g
89 stk.
på lager
Gruppe: X7383
DC Optocouplers
Darlington Transistor Output
Series: 4N_, 6N_
Case: DIP/DIL
En Stang = 48 stk
| Technical Specifications |
| Part Nr. | CTR | UCEO | ICmax | UCEsat | @IF/IC | Ton/off | @IC | [%] | [V] | [mA] | [V] | [mA] | [µs] | [mA] | 4N33 | >500 | >30 | 100 | 1,0 | 8/2 | 50 | 50 | 6N138 | >300 | 7 | - | 0,4 | 4,8/1,6 | 35 | 1,6 | 6N139 | >400 | 198 | - | 0,4 | 6,4/1,6 | 60 | 0,5 | |||||||||
| CTR = Current Transfer Ratio, UCEO = Collector Emitter Voltage At Open Base, ICmax = Max. Collector Current, UCEsat = Collector Emitter Saturation Voltage, IF =Forward Current, IC = Collector Current, Ton = Turn-On Time, Toff = Turn-Off Time | |||||||||||||||||||||||||||||||||||||||||||||||
 |
|||||||||||||||||||||||||||||||||||||||||||||||
| Terms of Delivery |
| Minimum order quantity: please see price list column "MOQ". |
|
| Manufacturer |
| Various If you have preference for a particular manufacturer, please inquire before placing your order. |
|
