Optoc. >3,5kV 30V 0,1A >20% DIP6
Varenummer:
79-041
Varekode: 4N25
Vægt: 0 g
131 stk.
på lager
Gruppe: X7282
DC Optocouplers
Transistor Output
Series: 4N_, 6N_
Case: DIP/DIL
Brug evt SPX33
| Technical Specifications |
| Part Nr. | CTR | UCEO | ICmax | UCEsat | @IF/IC | Ton/off | @IC | [%] | [V] | [mA] | [V] | [mA] | [µs] | [mA] | 4N25 | 100(>20) | >30 | 100 | 0,5 | 50/2 | 4 | 10 | 4N26 | 100(>20) | >30 | 100 | 0,5 | 50/2 | 4 | 10 | 4N27 | 100(>10) | >30 | 100 | 0,5 | 50/2 | 4 | 10 | 4N35 | 150(>100) | >30 | 100 | 0,3 | 10/0,5 | 10 | 2 | 4N37 | >100 | >30 | 100 | 0,3 | 10/0,5 | 10 | 2 | 6N136 | >19 | 15 | 16 | 0,4 | 1,1/16 | 1,5 | 16 | |||||||||
| CTR = Current Transfer Ratio, UCEO = Collector Emitter Voltage At Open Base, ICmax = Max. Collector Current, UCEsat = Collector Emitter Saturation Voltage, IF = Forward Current, IC = Collector Current, Ton = Turn-On Time, Toff = Turn-Off Time | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
 |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Terms of Delivery |
| Minimum order quantity: please see price list column "MOQ". |
|
| Manufacturer |
| Various If you have preference for a particular manufacturer, please inquire before placing your order. |
|
