PNP 100V 25A 125W TO218
Varenummer:
77-595
Varekode: BD250C
26 stk.
på lager
Bestil inden kl. 14 i dag for afsendelse i dag
Yderligere 20 stk. kan skaffes onsdag d. 25/11
- TRANSISTOR, PNP, TO-247
- Transistor Polarity: PNP
- Collector Emitter Voltage V(br)ceo: 100V
- Transition Frequency Typ ft: 3MHz
- Power Dissipation Pd: 125W
- DC Collector Current: 40A
- DC Current Gain hFE: 25
- Operating Temperature Min: -65°C
- Operating Temperature Max: 150°C
- Transistor Case Style: TO-247
- No. of Pins: 3
- SVHC: No SVHC (19-Dec-2012)
- Collector Emitter Voltage Vces: -1.8V
- Continuous Collector Current Ic Max: 25A
- Current Gain Hfe Max: 10
- Current Ic @ Vce Sat: 15A
- Current Ic Continuous a Max: 25A
- Current Ic hFE: 1.5A
- Full Power Rating Temperature: 25°C
- Gain Bandwidth ft Min: 3MHz
- Gain Bandwidth ft Typ: 3MHz
- Hfe Min: 10
- No. of Transistors: 1
- Operating Temperature Range: -65°C to +150°C
- Package / Case: TO-247
- Power Dissipation Ptot Max: 125W
- Voltage Vcbo: 115V
Produktfiler
