D-sub-hætte 9-pol lige sort
Varenummer:
160-777
Varekode: CGP09S
25 stk.
på lager
Manufacturer | CONNFLY | |
Type of enclosure for connectors | D-Sub | |
Connectors application | D-Sub 9pin, D-Sub HD 15pin | |
Spatial orientation | straight | |
Locking system | screws | |
Thread | UNC 4-40 | |
Closing system | screwed | |
Colour | black | |
Case | size 1 (DE) | |
Enclosure material | plastic | |
Kit contents | complete shell |
D-Sub Plastic Backshells
Series: CGP_G
Low Cost, UNC4-40 Thread
| Features |
| • Two-piece hoods made of plastic with straight cable entry • The cable strain relief is integrated in the hood • Retaining screws (UNC4-40) |
 |
| Dimensions |
| Part Nr. | Nr. of Poles | A | B | C | D | E |
| [mm] | [mm] | [mm] | [mm] | [mm] | ||
| CGP09G | 9 | 31,0 | 25,0 | 39,5 | 20,5 | 16,0 |
| CGP15G | 15 | 39,6 | 33,4 | 35,8 | 27,7 | 16,0 |
| CGP25G | 25 | 55,0 | 46,5 | 42,0 | 40,8 | 16,5 |
| ||||||
| Terms of Delivery |
| Minimum order quantity: 1 PKU = 1 pieces Delivery contents: screws supplied |
|
|
