Styrekabel 3x1,5mm²
Manufacturer
HELU 10092
Type of wire
control cable
Manufacturer series
OZ-500
Kind of cable
OZ
Cable structure
3x1,5mm2
Shield structure
unshielded
Rated voltage
0.3kV/0.5kV
Wire insulation material
PVC
Kind of core
Cu
Core structure
stranded
Number of cores
3
Core section
1,5mm2
Core marking
black, numbered
Insulation colour
grey
Cable external diameter
6.8mm
Kind of material
no flame propagation
Operating temperature
-40...80°C
Resistance to
most of chemical compounds, most of oils
Flexibility class
5
Earth core
none
CPR standard
Eca
- v/10 – Kr. 27,50
- v/25 – Kr. 21,25
- v/100 – Kr. 18,75
