Styrekabel 2x1,5mm²
Manufacturer
HELU 10090
Type of wire
control cable
Manufacturer series
OZ-500
Kind of cable
OZ
Cable structure
2x1,5mm2
Shield structure
unshielded
Rated voltage
0.3kV/0.5kV
Wire insulation material
PVC
Kind of core
Cu
Core structure
stranded
Number of cores
2
Core section
1,5mm2
Core marking
black, numbered
Insulation colour
grey
Cable external diameter
6,4mm
Kind of material
no flame propagation
Operating temperature
-40...80°C
Resistance to
most of chemical compounds, most of oils
Flexibility class
5
Earth core
none
CPR standard
Eca
- v/10 – Kr. 21,25
- v/25 – Kr. 13,75
- v/100 – Kr. 11,25
