HELU Styrekabel 3x0,75mm²
Manufacturer
HELU 10032
Type of wire
control cable
Manufacturer series
OZ-500
Kind of cable
OZ
Cable structure
3x0.75mm2
Shield structure
unshielded
Rated voltage
0.3kV/0.5kV
Wire insulation material
PVC
Kind of core
Cu
Core structure
stranded
Number of cores
2
Core section
0.75mm2
Core marking
black, numbered
Insulation colour
grey
Cable external diameter
5.6mm
Kind of material
no flame propagation
Operating temperature
-40...80°C
Resistance to
most of chemical compounds, most of oils
Flexibility class
5
Earth core
none
CPR standard
Eca
- v/10 – Kr. 16,25
- v/25 – Kr. 11,25
- v/100 – Kr. 10,00
