SMD MLC Capacitor 1,8nF 50V 5% NPO 0805

Varenummer: 156-142
Varekode: C2012NPO182JGT
300 stk. på lager
Vis lignende produkter i kategorien "SMD 0805"
GROUP:C5414
Type
Ceramic multilayer capacitor
Dielectric
COG (NPO)
Capacity
1,8 nF
Capacity Tolerance
±5%
Rated voltage DC
50 V
Assembly Type
SMD
Housing
0805
RoHS-Conform
Manufacturer
  • Darfon
Type
  • Ceramic multilayer capacitor
Series
  • C2012
Product group
  • C5414
Housing
  • 0805
Applications
  • Suitable for: LC and RC resonant circuits, filtering, time control.
Dielectric
  • COG (NPO)
Application
  • Low ESR
Assembly Type
  • SMD
Form of Delivery
  • strapped
Features

  • • Class I: Temperature-compensated type
    • Ultra-stable
    • Low ESR (frequency within 800 MHz)
    • Good frequency performance
    • No capacitance aging
    • Halogen-free

Dimensions and Weights

Dimension: Length
  • 2 mm
Dimension: Width
  • 1.25 mm
Dimension: Height
  • 1.45 mm

Operating conditions

Operating Temperature Min.
  • -55 °C
Operating Temperature Max.
  • 125 °C

Technical Features

Capacity
  • 1,8 nF
Capacity
  • 1,8
Capacity unit
  • nF
Capacity Tolerance
  • ±5%
Rated voltage DC
  • 50 V
Class
  • Class I
Insulation resistance
  • 100 GOhm



Inkl. moms
v/10 Kr. 0,89
  • v/100 – Kr. 0,19
  • v/1000 – Kr. 0,15
  • v/4000 – Kr. 0,12
