D-Sub-Plug 19-Pole Solder Cup

Name: D-Sub-Plug 19-Pole Solder Cup
SKU: 154675
Price: 100.00 DKK
Availability: InStock

Varenummer: 154-675

Varekode: SL19LR

2 stk. på lager

Bestil inden kl. 14 i dag for afsendelse i dag

Vis lignende produkter i kategorien "19-POLET"

Specifikationer

Stik-familie	D-Sub
Antal poler	19

Technical Specifications

Insulating Shell:

PBT, +30% Glass-filled, UL94V-0

Contacts:

Brass

Contact Surface

Snap-in Side:

Flash Gold Over Nickel

Soldered Side:

Tin Over Nickel

Housing Frame:

Steel, Tin-plated

Operating Current:

Dielectric Strength (For 1 Min.):

500V AC

Insulation Resistance:

1000MW at 500V DC

Contact Resistance, Max.:

20mW

Temperature Range:

-40...+105°C

Dimensions

								Part Nr.	Nr. of Poles	G	B	C	D	H	F			[mm]	[mm]	[mm]	[mm]	[mm]	[mm]	BL09LR	9	16,33	24,99	30,81	19,28	7,90	10,72	BL15LR	15	24,66	33,32	39,25	27,75	7,90	10,72	BL25LR	25	38,38	47,04	53,03	41,30	7,90	10,72	BL37LR	37	54,84	63,50	69,50	57,40	7,90	10,72

Manufacturer

Various

Gammelt varenummer: S779212 (779.212)
