Excellent high temperature, high voltage and current
ratings
For professional applications |
 |
Electrical Specifications
|
|
|
|
Taper: |
Linear |
Power Rating
(TU = 70°C): |
0,5W |
Operating Voltage,
Max.: |
200V DC |
Resistance
Tolerance: |
±10% |
End Resistance,
Min.: |
2W or 1%xRn |
Contact Resistance,
Min.: |
3W or 2%xRn |
Temperature Range: |
-55...+125°C |
|
Mechanical Specifications
|
|
|
|
Rotation |
Mechanical: |
260° |
Electrical: |
220° |
Stop Strength: |
50mNm |
Operating Torque: |
20mNm |
|
|
|
|
Length x Width x
Height: |
7,0x7,0x8,2mm |
Pitch: |
5x2,5mm |
|
|
Labelling |
| Resistance and production date code |
|
|
