Krympeflex 3:1 24,0mm 1m Sort
Varenummer:
153-970
Varekode: WBOX240SW-1
1 stk.
på lager
Bestil nu for afsendelse i morgen
| Features |
| Thin walled radiation-interlaced polyolefin Extremely flexible Flame retardant High operating temperature -55...+135°C |
 |
| Technical
Specifications |
|
|
| Continuous Operating Temperature: | -55...+135°C |
| Minimum Shrink Temperature: | 120°C |
| Dielectric Strength, Min.: | 20kV/mm |
| Flammability: | Flame Retardant |
|
|
| Dimensions |
| Part Nr. | D | d | W |
| [mm] | [mm] | [mm] | |
| WBOX30 | 3,0 | 1,0 | 0,55 |
| WBOX48 | 4,8 | 1,6 | 0,70 |
| WBOX60 | 6,0 | 2,0 | 0,65 |
| WBOX90 | 9,0 | 3,0 | 0,75 |
| WBOX120 | 12,0 | 4,0 | 0,75 |
| WBOX190 | 18,0 | 6,0 | 0,85 |
| WBOX240 | 24,0 | 8,0 | 1,00 |
| D = Inner Dimensions Before Shrinkage, d = Inner Dimensions After Shrinkage, W = Wall Strength | |||
|
|||
| Approvals |
  UL 224/Mil-1-23053/DEF.STAN 59-97 version
3 |
|
