Trimmer Top Adjust P10/12,5 4K7
Varenummer:
153-269
Varekode: PT15NV02472A2020
272 stk.
på lager
Gruppe:
C2145
PIHER Carbon Trimmers
Series: PT15
Top Adjust
Power: 0,25W
Shaft: Elongated Hole
Pitch: 10,0/12,5mm
Housing: 15mm
|
Features |
| High quality polyester substrate Sealed enclosure, dust and colophony proof, protected against harmful influences Double wiper, dual support Excellent stability, multipurpose applications as variable film potentiometer Resistant against cleaning agents, ultrasonic cleaning possible |
 |
|
Electrical Specifications |
|
|||||||||||||||
| Taper: | Linear | Power Rating (TU = 40°C): | 0,25W | Operating Voltage, Max.: | 250V DC | Resistance Tolerance | £1MW: | ±20% | >1MW: | ±30% | Temperature Range: | -25...+70°C | |||
|
|||||||||||||||
|
Mechanical Specifications |
|
|||||||||||
| Rotation | Mechanical: | 265 ±5° | Electrical: | 250 ±20° | Torque (3... 5U/s): | 0,5...2,5Ncm | Stop Torque: | 10Ncm | |||
|
|||||||||||
|
Dimensions |
|
|||||
| Diameter: | 15mm | Depth: | 6mm | ||
|
|||||
| Note |
| Please see product group C2190 for shafts and thumbwheels. |
|
| Labelling |
| Resistance and production date code |
|
| Terms of Delivery |
| Minimum order quantity: 1 PKU = 25 pieces |
|
| Manufacturer |
 |
| http://www.piher.net/ |
|
