Trådviklet modstand 50W 50Ω ±1 %
Varenummer:
150-345
Varekode: HS50-50R0F
0 stk.
på lager
Specifikationer
| Produkt | modstand |
|---|---|
| Komponenthus | aluminium |
| Modstand | 50 Ω |
| Effekt, max. | 50 W |
| Tolerance | ±1 % |
Features
| Hermetically sealed design aluminum housed Heat sink with high thermal contuctivity Mounts on chassis to utilize heat-sink effect Spot-welded compounds Meets applicable requirements of MIL-PRF-18546 |
 |
|
Technical Specifications |
|
|
| Resistance Tolerance: | ±1,0% |
| Power Rating (25°C): | 50W |
| Operating Voltage, Max.: | (PxR)1/2 |
| Insulation Resistance, Min.: | 103MOhm |
| Insulation Voltage: | 1000Vrms |
| Temperature Coefficient | |
| 0R1...0R99: | ±100ppm/°C |
| 1R...9R9: | ±50ppm/°C |
| from 9R9: | ±20ppm/°C |
| Temperature Range: | -55...+250°C |
| Terminal Strength, Min.: | 10lb |
| Derating: | Linear 25°C to 250°C (0W) |
