High-speed Si-gate CMOS SO-20
Philips PC74HCT4351T
FEATURES
• Wide analog input voltage range:
± 5 V
• Low “ON” resistance:
80 Ω (typ.) at VCC − VEE = 4.5 V
70 Ω (typ.) at VCC − VEE = 6.0 V
60 Ω (typ.) at VCC − VEE = 9.0 V
• Logic level translation: to enable 5 V logic to
communicate with ± 5 V analog signals
• Typical “break before make” built in
• Address latches provided
• Output capability: non-standard
• ICC category: MSI
- v/10 – Kr. 8,12
- v/100 – Kr. 5,00
