7 - 12V ELECTROMECHANICAL LOCK
High-end electromechanical lock micro door operator small electric lock drawer cabinet electronic lock automatic access control
Fit for drawer, cabinet, window or safe box high secure and more easy to operate connect to a stable power supply and which will open when it is energized Voltage: DC12V Current : ≥0.8A Working mode: power on unlock, power off lock Unlocking time: It is recommended to control in 0-10 seconds Extension length: 10mm Lock Size: 55 x 40 x 28(mm) Note: When using the electric lock, the unlocking time needs to be controlled within 0-10 seconds, avoiding the excessive unlocking time and causing the electric lock temperature to rise, resulting in damage to the electric lock. Package Included: 1 x Electric Cabinet Lock Electronic lock tongue direction can be adjusted,You can adjust it as you like on the picture, or leave a message to us the direction you need it.We send upward by default.
- Specification
Product code: SECU0001
Operating voltage (min): 7V
Operating voltage (Max): 12V
Operating current: 800mA at 12V
Rated power: 9.6W
Latch type: Fail secure
Max unlock time: 10 seconds.
- Model Number: LY-03
- Brand Name:
- voltage: DC12V
