Multiconnector 320V 3-pole Green
Varenummer:
144-224
Varekode: 2EDGKB-5.08-03P-14-1000AH
Vægt: 6 g
10 stk.
på lager
Bestil inden kl. 14 i dag for afsendelse i dag
Yderligere 820 stk. kan skaffes tirsdag d. 10/11
| 2EDGKB-5.08 |
 |
| Technical Specifications |
|
|
| Rated Voltage (IEC61984:2009): | 320V |
| Rated Current: | 18A |
| Rated Cross Section: | 2,5mm2 |
| Stripped Length: | 7...8mm |
| Insulating Material: | PA |
| Temperature Range: | -40°C...+105°C |
| Flammability Class: | UL94V-0 |
| Colour: | Green |
|
|
| Dimensions |
| Part Nr. | Length | Width | Hight |
| [mm] | [mm] | [mm] | |
| 2EDGKB-5.08-02P-14 | 10,16 | 12,6 | 26 |
| 2EDGKB-5.08-03P-14 | 15,24 | 12,6 | 26 |
| 2EDGKB-5.08-04P-14 | 20,32 | 12,6 | 26 |
| 2EDGKB-5.08-05P-14 | 25,4 | 12,6 | 26 |
| 2EDGKB-5.08-06P-14 | 30,48 | 12,6 | 26 |
Inkl. moms
v/10
Kr. 16,36
- v/30 – Kr. 13,50
- v/100 – Kr. 9,25
Produktfiler
Multiconnector 320V 3-pole Green
144-224
/ 2EDGKB-5.08-03P-14-1000AH
10 stk.
på lager
Bestil inden kl. 14 i dag for afsendelse i dag
Ved bestilling nu, får vi dem hjem tirsdag d. 10/11
| 2EDGKB-5.08 |
|
| Technical Specifications |
|
|
| Rated Voltage (IEC61984:2009): | 320V |
| Rated Current: | 18A |
| Rated Cross Section: | 2,5mm2 |
| Stripped Length: | 7...8mm |
| Insulating Material: | PA |
| Temperature Range: | -40°C...+105°C |
| Flammability Class: | UL94V-0 |
| Colour: | Green |
|
|
| Dimensions |
| Part Nr. | Length | Width | Hight |
| [mm] | [mm] | [mm] | |
| 2EDGKB-5.08-02P-14 | 10,16 | 12,6 | 26 |
| 2EDGKB-5.08-03P-14 | 15,24 | 12,6 | 26 |
| 2EDGKB-5.08-04P-14 | 20,32 | 12,6 | 26 |
| 2EDGKB-5.08-05P-14 | 25,4 | 12,6 | 26 |
| 2EDGKB-5.08-06P-14 | 30,48 | 12,6 | 26 |
