Crimp Housing 12-Pole P2,54
Varenummer:
143-648
Varekode: NSG254M-12
Vægt: 1 g
87 stk.
på lager
| NSG254M_ |
| Nylon Crimp Housing |
 |
| Features |
| • For easy manufacturing of multipolar connections |
|
| Technical Specifications |
|
|
| Insulation Shell: | Thermoplastic, UL94V-0 |
| Rated Current: | 3,0A |
| Rated Voltage: | 250VRMS/V DC |
| Dielectric Strength (1min.): | 1000VRMS |
| Temperature Range: | -25...+105°C |
|
|
| Dimensions |
| Pole | 02 | 03 | 04 | 05 | 06 | 08 | 10 | 12 | 20 |
| A [mm] | 5,68 | 8,22 | 10,76 | 13,30 | 15,84 | 20,92 | 26,0 | 30,48 | 51,4 |
| B [mm] | 2,54 | 5,08 | 7,62 | 10,16 | 12,7 | 17,78 | 22,86 | 27,94 | 48,26 |
|
|||||||||
Produktfiler
