SPS Case 156W 24V/6,5A
Varenummer:
142-629
Varekode: LRS-150-24
Vægt: 486 g
4 stk.
på lager
 |
| Features |
| • Enclosed case, screw terminals • LRS-150F: Universal input • LRS-150: 230V AC/115V AV by switch • Overload protection, pulsing hiccup shutdown, auto recovery • Protections: short circuit/over load/over voltage/ over temperature • Low profile • EN60335-1 (PD3), EN61558-1, -2, -16 |
|
| Technical Specifications |
|
|
| Input Voltage | |
| LRS-150: | 85...132V AC/170...264V AC (47...63Hz) |
| 240...370V DC | |
| Input Inrush Current, Max.: | 60A |
| Leakage Current, Max.: | 0,75mA |
| Output Voltage Adjustment: | ±10% |
| Over Load Protection: | 110...140% |
| Withstand Voltage | |
| I/P-O/P: | 3750V AC |
| I/P-FG: | 2000V AC |
| O/P-FG: | 1250V AC |
| Operating Temperature: | -30...+70°C |
| Operating Altitude, Max.: | 5000m |
| Weight: | 480g |
| I/P = Input, O/P = Output, FG = Frame Ground |
|
|
|
| Part Nr. | UA | IA | PA | DUA | URN | h |
| [V] | [A] | [W] | [%] | [mVp-p] | [%] | |
| LRS-150-12 | 12 | 0...12,5 | 150 | 1 | 150 | 87,5 |
| LRS-150-15 | 15 | 0...10 | 150 | 1 | 150 | 88,5 |
| LRS-150-24 | 24 | 0...6,5 | 156 | 1 | 200 | 89 |
| LRS-150-36 | 36 | 0...4,3 | 154,8 | 1 | 200 | 89 |
| LRS-150-48 | 48 | 0...3,3 | 158,4 | 1 | 200 | 90 |
| UA = Output Voltage, IA = Output Current Range, PA = Output Power, DUA = Output Voltage Tolerance, URN = Ripple & Noise, h = Efficiency | ||||||
|
||||||
| Note |
| These power supplies are considered as a component that has to be installed in a final equipment. |
|
| Labelling |
   |
|
| Terms of Delivery |
| Minimum order quantity: 1 PKU = 1 piece |
|
| Manufacturer |
 |
Inkl. moms
Kr. 229,00
- v/3 – Kr. 219,00
